Plate Bending Machine

Get a Price/Quote

MOQ : 1 Unit

Plate Bending Machine Specification

Color
Blue & Yellow

Condition
New

Voltage
Optional (if Motorized): 415 V

Output
Uniform bending of metal plates

Dimension (L*W*H)
2400 mm x 900 mm x 1200 mm

Power
Manual / Optional Motorized

Manufacturing Year
2023

Machine Type
Plate Bending Machine

Feature
Manual/Mechanical operation, Robust construction, Easy to operate, Precision forming

Weight
Approximately 1400 kg

Used For
Sheet metal bending and forming

Capacity
4 mm plate thickness x 2500 mm length

Plate Rolling Speed
3-4 m/min (if motorized)

Control Type
Hand Lever / Gear Wheel

Surface Finish
Powder coated

Min. Bending Diameter
200 mm

Number of Rolls
3 rolls

Installation
Floor mounted

Noise Level
Low (manual operation)

Safety Features
Emergency stop (if motorized), Mechanical safety locks

Drive Type
Gear Driven (Manual/Optional Motorized)

Roll Diameter
110 mm

Max. Bending Width
2500 mm

Applications
Automobile, Construction, Fabrication, Tank manufacturing

Roll Material
High-grade steel

Plate Bending Machine Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
1 Unit Per Week

Delivery Time
1 Week

About Plate Bending Machine

Explore the superb possibilities of metal forming with our new Plate Bending Machine, crafted using high-grade steel for robust durability. Featuring three majestic rolls at a 110 mm diameter, this machine delivers sensational performance with a max bending width of 2500 mm and precision forming for plates up to 4 mm thick. Gear-driven-manual or optionally motorized-it ensures value in every operation. With powder-coated surfaces and enhanced safety features, it offers easy operation, low-noise output, and uniform results across automobile, tank, and construction applications.

Exceptional Features & Simple Operation

This Plate Bending Machine stands out with its strong mechanical construction, manual or optional motorized gear drive, and powder-coated finish. Designed for precise, uniform plate bending, it is easy to operate using a hand lever or gear wheel control. Suitable for bending up to 4 mm thick, 2500 mm wide sheets, it's ideal for fabrication, automobile, and tank manufacturing, making it a reliable investment for consistent use in directional forming tasks.

Sample Delivery & Market Access

Sample units of our Plate Bending Machine can be dispatched as per customer request, ensuring confident purchasing. Delivered swiftly via FOB Port to the main domestic market, including all major industrial hubs across India, we coordinate each drop-off for seamless installation. As a manufacturer, distributor, and supplier, we guarantee prompt dispatching and responsive after-sales support, giving customers full value and convenience from order to operation.

FAQ's of Plate Bending Machine:

Q: How is the Plate Bending Machine powered and what are the available options?

A: The Plate Bending Machine is primarily operated manually using a hand lever or gear wheel, but an optional motorized version is available. The motorized option operates on 415 V and offers plate rolling speeds of 3-4 m/min.

Q: What materials and thicknesses can be processed with this machine?

A: It is designed to bend and form high-grade steel sheets with a maximum plate thickness of 4 mm and a width up to 2500 mm, delivering uniform results for various fabrication needs.

Q: What safety features are included with the machine?

A: For maximum operator safety, the machine can be equipped with emergency stop features (on motorized models) and reliable mechanical safety locks, ensuring secure operation throughout the bending process.

Q: Where can the Plate Bending Machine be installed, and what are its space requirements?

A: This machine is floor-mounted, with compact overall dimensions of 2400 mm (L) x 900 mm (W) x 1200 mm (H), making it suitable for a range of workshop environments without occupying excessive space.

Q: What types of industries commonly use this machine?

A: Industries such as automobile manufacturing, construction, tank fabrication, and general metalworking commonly benefit from the machine's precision forming capabilities and robust value.
